Proximity Probe – Housing Assembly 21000-16-05-15-102-03-02

Description

Ultra-Short Range Detection System

Key Specifications for 21000-16-05-15-102-03-02

• Brand: Bently Nevada
• Full Model: 21000-16-05-15-102-03-02
• Construction: Forged aluminum housing with electropolished 304SS internals

Precision Engineering Details

• Measurement System
  • Probe Resolution: 0.0001″ (2.5μm)
  • Effective Range: 0.2″ ±0.02″ (5.08mm ±0.5mm)
  • Nonlinearity: <±0.5% FSO
• Electrical Configuration
  • Output: RS-422 differential signal
  • Update Rate: 50kHz sampling
  • EMC Compliance: MIL-STD-461G
• Environmental Tolerance
  • Temp Range: -196°C to +150°C (cryogenic to extreme heat)
  • Pressure Rating: 5000 psi (344 bar)
  • Radiation Hardness: 100 kRad TID

Configuration Breakdown

• 16 – 8mm Micro-Probe
  • Frequency Response: 0-25 kHz
  • Target Compatibility: Non-ferrous metals
• 05 – Ultra-Short Cable
  • Length: 0.5m (20″) double-shielded
  • Impedance: 50Ω ±1%
• 15 – Precision Standoff
  • Material: Invar 36 (low thermal expansion)
  • Surface Finish: 16μin Ra
• 102 – Minimal Penetration
  • Requires 0.1″ counterboring depth
  • Axial Clearance: 0.04″ minimum

Certification Matrix

• Explosion Protection
  • ATEX Zone 0 (Category 1G)
  • IECEx Ex ia IIC T4 Ga
• Industry Compliance
  • ASME B40.100-2013
  • NEMA 4X/IP66

Specialized Application

Deployed in space simulation chambers for rocket engine turbopump monitoring, maintaining measurement stability during thermal cycling between -180°C and +120°C.

Complete Package

• Vacuum-rated probe assembly
• Cryogenic O-ring kit (Kalrez® 6375)
• Alignment laser tool
• NIST-traceable calibration report
