Description
Description
The Bently Nevada 3300 XL 8mm Probe with Armor (Model 330141-08-90-11-05) combines rugged industrial design with advanced leak-proof technology. Designed for hazardous environments, this probe features a 9.0-meter (29.5 ft) FluidLoc cable with a ClickLoc connector protector, ensuring reliable performance in oil-rich or humid conditions. Built with patented TipLoc and CableLoc technologies, it achieves 330 N (75 lbf) pull strength and a Viton® O-ring seal for pressure resistance. The 8mm PPS plastic tip and AISI 303/304 stainless steel casing provide unmatched durability, while CSA, ATEX, and IECEx certifications guarantee compliance in explosive atmospheres.
Technical Data
| Parameter | Specification |
|---|---|
| Brand | Bently Nevada |
| Model Number | 330141-08-90-11-05 |
| Suffix Breakdown | -08: 0.8″ case length -90: 9.0m cable -11: FluidLoc cable with ClickLoc connector protector -05: CSA, ATEX, IECEx certifications |
| Nominal DC Resistance | 9.87 ± 0.50 Ω (9.0m length) |
| Cable Jacket Material | Fluoropolymer (oil-resistant, UL 94V-0 rated) |
| Incremental Scale Factor | 7.87 V/mm ±6.5% (9m systems) |
| Insulation Resistance | >100 MΩ at 500 V DC (conductor to shield) |
| Probe Tip Material | Polyphenylene Sulfide (PPS) |
| Case Material | AISI 303/304 Stainless Steel (corrosion-resistant) |
| Temperature Range | Standard: -52°C to +177°C ETR Tip: -52°C to +218°C |
| Connector Durability | 1,000+ mating cycles (IEC 60512-9-1 compliant) |
| Weight | 323 g/m (11.4 oz) |
| Sealing Material | Viton® O-ring (non-pressure tested) |
| Ingress Protection | IP67 (connector protector) |
| Vibration Resistance | 15 g RMS (10–2000 Hz, ISO 10816-3) |
Contact Support
For certification documents or custom configurations:
sales@ubestplc.com
Explore more detailed information in official datasheet here: 3300 XL 8 mm Proximity Transducer System Datasheet
