???? Product Overview: Bently Nevada 330905-00-25-10-02-05 NSv Proximity Probe
Brand New & Original with 12-Month Factory Warranty. Direct replacement for 3300 RAM probes, offering enhanced chemical resistance and superior side-view performance for industrial sensing applications.
???? Suffix Breakdown & Configuration for 330905-00-25-10-02-05
- • Model: 330905
- • Thread: M10X1 (no armor)
- • Unthreaded Length: 00 mm (-00-)
- • Case Length: 250 mm (-25-)
- • Total Probe Length: 1.0 meter / 39 inches (-10-)
- • Connector: ClickLoc Mini-Coaxial with standard cable (-02-)
- • Agency Approvals: Multiple Certifications (-05-)
⚡ Key Performance Metrics
- • DC Resistance: 4.2Ω ±0.5Ω (1.0m probe)
- • Frequency Response: 0-10kHz (±3dB) with 305m field wiring
- • Linear Range: 0.25-1.75mm (10-70 mils)
- • Scale Factor: 7.87V/mm ±12.5%
- • Max Torque: 0.56N·m (5 in·lb)
???? Installation & Compatibility
- • Case Length: 250 mm (optimized for deeper installations)
- • Thread Engagement: 15mm max
- • Cable Specs: 75Ω coaxial FEP, 25.4mm bend radius
- • Operating Temp: -52°C to +177°C (extreme environment rated)
???? Technical Support & Customization
For pressure testing requests or bulk orders:
???? sales@ubestplc.com
