Schneider Electric 140ATI03000 Thermocouple Input Module
Precise temperature monitoring made simple. The 140ATI03000 module reads 8 thermocouple sensors with high accuracy. It supports J, K, T, E, R, S type thermocouples. Perfect for industrial heating and process control.
- Full documentation: Download Installation Manual
- Expert support: Contact: +86 158 8020 0923
- Fast delivery: FedEx, UPS, DHL available worldwide
Module Overview
The 140ATI03000 connects temperature sensors to your Modicon Quantum PLC. It has 8 isolated input channels. Each channel has its own status LED. The module includes cold junction compensation. This ensures accurate temperature readings. For technical Support, Contact: +86 158 8020 0923.
Technical Specifications
Brand: Schneider Electric
Model: 140ATI03000
Module Type: Thermocouple Input
Channels: 8
Thermocouple Types: J, K, T, E, R, S
Temperature Range: -270°C to +1665°C
Resolution: 16-bit (0.1°C)
Accuracy: ±2°C + 0.1% of reading
Update Time: 1000 ms per channel
Isolation: 1780V AC channel-to-bus
Power Consumption: 280 mA
Operating Temperature: 0°C to 60°C
Quick Installation Guide
Mount the 140ATI03000 in your Quantum rack. It needs 10 input words in your PLC configuration. Connect thermocouples using proper extension wires. The module automatically detects broken wires.
5 Important Questions
1. What thermocouple types are supported?
J, K, T, E, R, S types covering -270°C to 1665°C range.
2. How accurate are the temperature readings?
Very accurate: ±2°C plus 0.1% of the measured value.
3. Does it need special wiring?
Use proper thermocouple extension wires. Avoid copper wires for best results.
4. What is cold junction compensation?
It automatically corrects for temperature changes at the module connection points.
5. How are wiring faults detected?
The module detects broken wires and shows red LED alarms for each channel.
Quality Assurance
This module meets UL 508 and CSA standards. It has 1780V isolation for safety. Works reliably in harsh industrial environments. We offer a 12-month warranty.
