Description
Advanced Ethernet Network Module for M340 Platform
The BMXNOE0110 delivers robust Ethernet connectivity for Modicon M340 automation systems. This network module features comprehensive web services and data management capabilities. It includes 16MB internal RAM and comes with flash memory card.
Technical Specifications
- Brand: Schneider Electric
- Model: Modicon M340 BMXNOE0110
- Ethernet Port: 1 RJ45 10/100 Mbit/s
- Internal Memory: 16MB RAM for web pages
- Memory Card: Includes 16MB flash card
- Power Consumption: 90mA at 24V DC
- Operating Temperature: 32°F to 140°F (0°C to 60°C)
- Module Weight: 0.4 lb (0.2 kg) compact
- Protection Rating: IP20 industrial grade
Environmental Specifications
- Temperature Range: 0°C to 60°C operation
- Humidity Range: 10% to 95% non-condensing
- Protection Class: IP20 dust and moisture
- Industrial Use: Factory environment rated
- Safety Standards: CE and UL certified
Packaging & Shipping
- Unit Package: Individual box packaging
- Package Size: 4.72″ × 4.53″ × 2.20″
- Package Weight: 8.395 oz (238g)
- Bulk Package: 15 units per carton
- Shipping Methods: FedEx, UPS, DHL available
Installation Guide
- Install in Modicon M340 compatible rack
- Use internal backplane power supply
- Connect Ethernet cable to RJ45 port
- Use reset button for cold restart
- Monitor six status LEDs for operation
Frequently Asked Questions
- What web services does this module support?It provides SOAP XML web services and configurable web server.
- Is the memory card included with purchase?Yes, a 16MB flash memory card comes with the module.
- What network protocols are available?It supports Modbus TCP, Global Data, and I/O scanning.
- How much internal memory is available?The module has 16MB internal RAM for web pages.
- What is the reset button used for?The reset button performs cold restart of the module.
Documentation & Support
- Includes 12-month product warranty coverage
- For technical Support, Inquiry, Contact: +86 158 8020 0923
- Professional installation support available
