Modicon M340 Processor: Advanced Network Control
The BMXP3420302 processor delivers powerful automation control for Modicon M340 systems. This unit manages 1024 discrete and 256 analog I/O points with integrated Ethernet and CANopen. Download the complete installation and programming manual for your BMXP3420302 to get started.
Core Processing Capabilities
- Brand & Model: Schneider Electric BMXP3420302
- Platform Series: Modicon M340 Automation Platform
- I/O Capacity: 1024 discrete / 256 analog points maximum
- Memory Capacity: 4096 kB internal RAM with included 8MB memory card
- Processing Speed: 0.12 µs for Boolean instructions, 8.1K instructions/ms
- Task Management: 64 event tasks with master and fast periodic tasks
- Application Channels: 36 dedicated channels for specialized functions
Network & Communication Features
- Ethernet Port: 10/100 Mbit/s TCP/IP with RJ45 connector
- CANopen Master: SUB-D 9 port supporting 20 kbit/s to 1 Mbit/s
- USB Interface: 12 Mbit/s programming and configuration port
- Device Capacity: Manages 63 CANopen devices on the network
- Protocol Support: Modbus TCP, SNMP, and web server functionality
- Expansion Slots: Supports 2 Ethernet and 4 AS-Interface modules
Physical Specifications & Operation
- Power Requirements: 135 mA at 24V DC via backplane connection
- Operating Temperature: 32°F to 140°F (0°C to 60°C) range
- Environmental Protection: IP20 rating for industrial environments
- Status Indicators: 10 LED indicators for network and system status
- Product Weight: 0.474 lb (0.215 kg) compact design
- Rack Configuration: 4 racks maximum with 11 slots each
Packaging & Shipping Details
- Unit Package: 1 processor module per individual box
- Package Dimensions: 4.61 x 4.33 x 2.17 inches compact size
- Unit Weight: 8.783 ounces (249 grams) including packaging
- Bulk Package: 15 modules per master shipping case
- Case Dimensions: 15.75 x 11.81 x 5.91 inches storage efficient
- Case Weight: 9.059 pounds (4.109 kg) total shipping weight
- Shipping Options: FedEx, UPS, DHL express delivery available
- Warranty Coverage: 12-month quality assurance guarantee
Technical Frequently Asked Questions
- What memory card comes with this processor?
- It includes an 8MB BMXRMS008MP card for program backup and web server functions.
- How many Ethernet devices can connect to this processor?
- The built-in Ethernet port supports multiple simultaneous TCP/IP connections.
- What is the maximum CANopen network distance?
- It supports up to 8202 feet (2500m) at lower data rates of 20 kbit/s.
- Does this processor support web server functions?
- Yes, the included memory card activates a standard class B10 web server.
- What is the power consumption of this module?
- It uses 135 mA at 24V DC from the main rack power supply.
