Description
Dual Protocol M340 Processor with CANopen & Ethernet
The BMXP3420302CL offers flexible communication options for diverse industrial applications. This powerful processor supports both CANopen and Ethernet protocols simultaneously. It requires a separate memory card for complete operation.
Technical Specifications
- Brand: Schneider Electric
- Model: Modicon M340 BMXP3420302CL
- I/O Capacity: 1024 discrete + 256 analog maximum
- Processing Speed: 6.4-8.1K instructions/ms
- Communication Ports: Ethernet, CANopen, USB
- Memory Configuration: 4MB internal RAM total
- Power Requirement: 135mA at 24V DC
- Operating Range: 0°C to 60°C industrial
- Module Weight: 0.215 kg compact design
Communication Protocols
- Dual network support: CANopen and Ethernet TCP/IP
- CANopen master for 63 devices maximum
- Ethernet 10/100 Mbit/s with Modbus TCP
- USB programming port 12 Mbit/s speed
- SNMP network management capability
- Web server functionality enabled
Memory & Processing
- Internal Memory: 4MB total RAM capacity
- Program Space: 3.5MB for application code
- Data Storage: 256KB internal data memory
- Note: Memory card required separately
- Task Handling: 64 event tasks supported
- Execution Speed: 0.12µs for Boolean logic
Environmental Ratings
- Protection Class: IP20 standard rating
- Temperature Range: 0°C to 60°C operation
- Humidity Range: 10% to 95% non-condensing
- Hazardous Areas: Class I Division 2 approved
- Industrial Standards: IEC 61131-2 compliant
Packaging Information
- Unit Package: Individual protective box
- Package Dimensions: 12.0×11.5×5.5 cm
- Unit Weight: 251 grams packaged
- Bulk Package: 15 units per carton
- Shipping Options: FedEx, UPS, DHL express
Installation Requirements
- Install in compatible M340 rack system
- Purchase memory card separately for operation
- Connect to 24V backplane power supply
- Use shielded cables for communication ports
- Monitor ten status LEDs for system health
Frequently Asked Questions
- What memory card does this processor need?
You need to purchase a compatible memory card separately. - How many CANopen devices can it control?
The processor manages up to 63 CANopen devices. - What is the Ethernet port speed?
It supports both 10 Mbit/s and 100 Mbit/s speeds. - Can I use both CANopen and Ethernet together?
Yes, both protocols operate simultaneously. - What is the power consumption?
It uses 135mA at 24V DC from the backplane.
Support & Documentation
- Includes 12-month comprehensive warranty
- For technical Support, Inquiry, Contact: +86 158 8020 0923
- Memory card must be purchased separately
