Schneider Electric 140DAI45300 48V AC Input Module
Monitor higher voltage devices with the 140DAI45300. This 32-input module handles 48V AC signals. The 140DAI45300 is perfect for industrial applications needing higher voltage inputs.
Main Benefits
- 32 input channels for 48V AC signals
- Four isolated channel groups for safety
- Works with ProWORX 32 and Unity Pro software
- LED status lights for every channel
- FM Class 1 Division 2 safety rating
Technical Details
Brand: Schneider Electric
Model: 140DAI45300
Type: Discrete Input Module
Channels: 32 inputs
Voltage: 48V AC
Input Current: 9.8-11.7 mA
Power Use: 10.9W max
Bus Current: 250 mA
Response Time: 0.75-12.3 ms
Isolation: 1780 Vrms between groups
Frequency: 47-63 Hz
Temperature: 0°C to 60°C
Weight: 0.3 kg
Easy Installation
Plug into Quantum backplane. Connect 48V AC signals. All 32 channels are ready.
FAQ – Common Questions
What voltage does this module use?
Designed for 48V AC input signals.
How many channel groups are there?
Four isolated groups for safe operation.
What is the input current range?
Between 9.8 mA and 11.7 mA.
What is the maximum voltage input?
Handles up to 56V continuous operation.
What are the input impedance values?
5600 to 6800 Ohm capacitive impedance.
Shipping & Protection
Fast shipping via FedEx, UPS, DHL. Comes with 12-month warranty.
Need ? Have an ? via WhatsApp: +86 158 8020 0923.
Get User Manual
Download complete installation guide:
Download Modicon Quantum Manual (PDF)
