Product Overview
This is the genuine Bently Nevada 330901-00-08-05-02-05, a core 3300 NSv Proximity Probe for machinery health. It offers precise vibration and position measurement. Its compact 0.8-inch case and short 0.5-meter cable are perfect for tight spaces. Questions? Chat with us on WhatsApp: +86 158 8020 0923.
Key Features & Tech Specs
- Complete Part: 330901-00-08-05-02-05
- Base: 330901 (1/4-28 UNF Thread)
- Unthreaded: 00 (0.0 inch)
- Case Size: 08 (0.8 inch)
- Wire Length: 05 (0.5 meter / 20 inch)
- Connection: 02 (ClickLoc Connector)
- Approval: 05 (Multiple Agencies)
- Core Job: Measures shaft vibration and position using eddy currents.
- Key Ratings:
- Temp Range: -52°C to +177°C
- Cable Type: 75 Ω Coaxial with FEP insulation.
- Resistance (0.5m): 4.0 ± 0.5 ohms.
- Build Quality:
- Case: Strong AISI304 Stainless Steel.
- Tip: Durable PPS Material.
- Seal: Reliable Viton O-ring.
- Install Torque: Use 11.3 N•m (100 in-lb) maximum. Be careful with the first three threads.
Setup & Use Guide
- Mount the probe securely using the correct torque.
- Connect the ClickLoc connector until it clicks.
- Ensure the target surface is clean and smooth.
- Keep the probe above -34°C for long-term storage.
Compatibility & Support
- Made for Bently Nevada 3300 NSv systems.
- Works with monitors that use the standard 200 mV/mil output.
- Comes with a full 12-month warranty for peace of mind.
- Ships fast via FedEx, UPS, or DHL.
Expert FAQs
Q: What does the ’05’ approval option mean?
A: It means this probe meets standards for use in many different countries and industries.
Q: Why is the cable only 0.5 meters long?
A: This short length is for applications where the monitor is very close to the measurement point, reducing clutter.
Q: How do I avoid damaging the threads during installation?
A: For the first three threads, use a lower torque (7.5 N•m). Then use the full recommended torque for the rest.
Q: What is the temperature classification T2?
A: T2 means the probe is safe for use in hazardous areas with an ambient temperature up to 177°C.
Q: From experience, when should I choose this short probe?
A: Choose model 330901-00-08-05-02-05 for gearbox monitoring, small motors, or any place with very limited space for cable routing.
Q: I need a different length or thread. How do I choose?
A> Look at the part number codes. Change the ’08’ (case length), ’05’ (cable length), or the base model number for different threads. We can help you find the right code.
