Short Case M10 Probe | Bently Nevada 330103-00-06-15-02-CN with 1.5m Cable

Description

Compact Design with Extended Reach

The Bently Nevada 330103-00-06-15-02-CN is a versatile 8mm proximity probe. It features a short 60mm case and a long 1.5-meter cable. This M10 metric probe is ideal for tight spaces where the monitor is not nearby. It offers flexible installation for various industrial machines.

Key Benefits for Your Application

• Space-Saving Design: Short 60mm overall case fits where longer probes cannot.
• Reduced Wiring: 1.5-meter integrated cable minimizes the need for extra extension cables.
• Full Threaded Shank: 0mm unthreaded length allows maximum engagement in the mounting hole.
• Country-Specific Compliance: “CN” option allows configuration for local market certification needs.
• Universal Performance: Delivers the same reliable vibration data as all 3300 NSv Probes.

Model Number Configuration Breakdown

The part number 330103-00-06-15-02-CN details every feature:

• Product Family (330103): 3300 XL 8mm Probe, M10x1, No Armor
  • ► Option -00: Unthreaded Length = 0 mm (Fully Threaded)
  • ► Option -06: Overall Case = 60 mm
  • ► Option -15: Cable Length = 1.5 Meters
  • ► Option -02: Connector = ClickLoc Coaxial
  • ► Option -CN: Agency Approval = Country Specific

Technical Specifications

• Product: Bently Nevada 3300 XL 8mm Probe
• Exact Model: 330103-00-06-15-02-CN
• Compliance: Configurable for country-specific standards.
• Electrical Performance:
  • Linear Range: 2.0 mm
  • Recommended Gap: -9 Vdc
  • Probe Resistance (1.5m): 7.73 Ω ± 0.50 Ω
• Physical Dimensions:
  • Mounting Thread: M10 x 1.0
  • Max Thread Engagement: 15 mm
  • Case Length: 60 mm
  • Materials: Stainless Steel Case, PPS Tip
• Torque Specifications:
  • Standard Mount (Full Thread): 11.2 N•m Rec. / 33.9 N•m Max
  • First 3 Threads Only: 7.5 N•m Rec. / 22.6 N•m Max
• Environmental:
  • Operating Temp: -52°C to +177°C
  • Humidity: Excellent stability (<3% change)

Installation & Mounting Guide

• This probe is fully threaded. Screw it directly into an M10x1 hole.
• Do not engage more than 15mm of thread.
• Use a torque wrench. For full engagement, tighten to 11.2 N•m (100 in-lbf).
• The long 1.5m cable helps when the junction box is not close to the probe.

Ordering, Warranty & Fast Shipping

• Package Contents: One probe with 1.5m cable and ClickLoc connector.
• Customer Assurance: Full 12-month warranty on materials and workmanship.
• Global Delivery: Shipped quickly via FedEx, UPS, or DHL.
• Need Help? Contact our team: +86 158 8020 0923 (WhatsApp).

Professional FAQ & Guidance

Dimensions & Mounting

• What does “0mm unthreaded length” mean for installation?
• It means the entire shank of the probe is threaded (M10x1). There is no smooth section. It screws directly into the mounting hole from the very start of the case.
• Why are there two different recommended torque values?
• The higher torque (11.2 N•m) is for when the probe is fully engaged in the thread (up to 15mm). The lower torque (7.5 N•m) is for special cases where only the first 3 threads are engaged. Always follow the guideline that matches your installation.

Certification & Selection

• What does “Country Specific (CN)” approval mean?
• This indicates the probe can be supplied to meet specific certification requirements of a particular country or region, which may differ from standard ATEX/IECEx. You must specify the needed certification when ordering the 330103-00-06-15-02-CN.
• Is this probe suitable for high-temperature applications?
• Yes, its standard range is up to 177°C. For higher temps, ensure your selected Temperature Classification (e.g., T1, T2) matches the ambient temperature in your application, as per the temperature schedule.

Purchasing & Support

• Can I get urgent delivery for this model?
• Yes. We stock the 330103-00-06-15-02-CN and use express carriers (FedEx/UPS/DHL). Contact us for expedited shipping options to meet your project deadline.
