Description

MTL4573 Temperature Transmitter: Connect Any Sensor Safely

The MTL4573 is a smart and flexible temperature transmitter. It takes signals from thermocouples or RTD sensors in hazardous areas and converts them to a safe 4-20mA signal. It works with many sensor types and is easy to set up with a computer.

Technical Details

• Brand & Model: MTL MTL4573 Temperature Transmitter
• Input Types: J,K,T,E,R,S,B,N Thermocouples / 2-3-4 wire RTDs (Pt100, Ni100, Cu50)
• Output Signal: 4 to 20mA
• Maximum Load: 600Ω
• Power Supply: 20-35V DC
• Power Consumption: 50mA at 24V
• Calibration Accuracy: Better than ±0.05%
• Response Time: 500ms
• CJC Error: ≤ 1.0°C
• Operating Temp: -20°C to +70°C

Setup & Use

Mount on a DIN rail. Connect your sensor and power. Use the PCS45 software on a PC to set your temperature range, sensor type, and alarms. The MTL4573 is ready for use.

Frequently Asked Questions

• Q1: What software do I need to configure it?
  A1: You need MTL’s PCS45 software and a PCL45USB interface on a PC.
• Q2: Does it work with 3-wire RTDs?
  A2: Yes, it supports 2-, 3-, and 4-wire RTD connections.
• Q3: What is early burnout detection?
  A3: It can detect when a thermocouple wire is starting to fail before it breaks completely.
• Q4: Can I use it without a computer?
  A4: Basic operation is possible, but a computer is needed for initial setup and configuration.
• Q5: What is the output if the sensor fails?
  A5: You can set the output to go high or low to trigger an alarm in your control system.
