XL Series Extension Cable Bently Nevada 27490-0370-00 Proximitor Lead

Description

Product Introduction

• Manufacturer
  • Bently Nevada
• Part Number
  • 27490-0370-00
• Product Line
  • XL Proximitor Extension Cable
• Category
  • Industrial Sensor Connection Cable
• This cable links probe and proximitor.
• It keeps signal loss very low.
• Design suits critical machines.

Structural Design

• Three-conductor triaxial layout.
• High-purity copper conductors.
• Continuous shield for noise control.
• Flexible jacket for easy routing.

Core Electrical Properties

• Center Conductor Resistance
  • 0.36 Ω per meter
  • 0.11 Ω per foot
• Shield Resistance
  • 0.023 Ω per meter
  • 0.007 Ω per foot
• Capacitance
  • 63 pF per meter nominal
  • 19.2 pF per foot nominal

Physical Characteristics

• Total Length
  • 37.0 ft / 11.28 m
• Armor Option
  • No armor
• Small bend radius supports tight panels.

Extended Technical Data

• Rated insulation voltage up to 250 V.
• Signal attenuation remains very low.
• Stable impedance across temperature range.
• Excellent shielding effectiveness.

Wiring and Installation

• Field Wiring Size
  • 16 to 24 AWG supported
  • 0.2 to 1.5 mm² range
• Recommended Cable Type
  • Shielded triaxial cable
• Pre-terminated ends reduce errors.

Distance Capability

• Maximum Supported Length
  • 305 m / 1,000 ft
• Maintains signal accuracy over distance.

Operational Benefits

• Improves sensor measurement stability.
• Reduces electrical noise impact.
• Supports high-resolution monitoring.
• Proven in continuous operation.

Compatibility

• Designed for XL series proximity probes.
• Works with Bently Nevada proximitor sensors.
• Fits standard monitoring racks.

Typical Use Scenarios

• Turbine shaft position measurement.
• Compressor vibration monitoring.
• Motor and pump protection systems.
• Critical rotating assets.

Packaging and Delivery

• Factory sealed industrial packaging.
• Clear model and length marking.
• Shipped via FedEx, UPS, or DHL.

Warranty Policy

• 12-month warranty from shipping date.
• Covers material and workmanship issues.
• Technical support available.

Professional FAQ

• Why is low capacitance important?
• It keeps probe signals clean and accurate.
• Can this cable be shortened on site?
• Cutting is not recommended for accuracy.
• Does cable length affect calibration?
• Yes, length must match system setup.
• Is armor needed in most plants?
• Armor helps only in heavy mechanical risk areas.
• What causes most signal issues?
• Poor grounding during installation.
