Description
Product Overview
- The Yokogawa SSC60D-S2512 is the main brain for ProSafe-RS safety systems.
- It keeps your plant running safely by using a Dual-Redundant backup design.
- This unit automatically stops machines during Emergency Shutdown (ESD) events.
- It connects to your network using high-speed Vnet/IP for fast data sharing.
- The rugged build protects against gas and salt with G3 corrosion coating.
Technical Specifications
- Brand: Yokogawa
- Model: SSC60D-S2512
- Series: ProSafe-RS Safety Series
- Processors: Two S2CP471 or SCP461 modules for 100% backup.
- Power Input: 220-240 V AC (Supports two power feeds).
- Network Speed: 100 Mbps for fast, reliable communication.
- Network Port: Standard RJ45 (uses CAT5e cables).
- Capacity: Connects up to 110 I/O modules with expansion.
- Temperature: Works best between -20 and 40 °C.
- Protection: ISA G3 coating for harsh chemical air.
- Storage: Flash Memory saves your program even without power.
- Size: 482.6 mm x 266 mm x 207 mm (Standard rack size).
- Weight: 8.5 kg (Solid industrial build).
Installation and Maintenance
- Place ESB bus modules in slots 7 and 8 for node connections.
- Keep cables under 100 meters for the best signal.
- The S9450FE battery lasts for 3 years before needing a swap.
- Check LED lights on the front to see if the unit is healthy.
- You can pull out and replace modules while the system is still running.
Shipping and Warranty
- Delivery: Shipped fast by DHL, FedEx, or UPS.
- Warranty: Comes with a full 12-month quality guarantee.
- In the Box: One SSC60D-S2512 unit with all main modules inside.
- Quality: 100% Original Yokogawa factory parts.
Typical Applications
- Oil and gas refinery Emergency Shutdown systems.
- Fire and Gas (F&G) detection in chemical plants.
- Boiler safety and burner control in power plants.
- Critical cooling systems for large factories.
Buying Guide
- Check your power source: This model is for 220-240V AC.
- If your room is hotter than 40 °C, choose the -F model with fans.
- Make sure you have the CFS1300 license for your software.
- Order the -2 type if you need Dual-Redundant power for extra safety.
Frequently Asked Questions (FAQ)
- What happens if one processor stops working?
- The backup processor takes over instantly so the plant does not stop.
- Can I use regular internet cables?
- Yes, use CAT5e or better cables with RJ45 ends.
- How do I know the battery is low?
- The system will show a maintenance alarm before the 3-year limit.
- Is it okay for dusty or salty air?
- Yes, the G3 coating protects the internal parts from corrosion.
