Bently Nevada 3300 XL 11mm Probe (330702-00-24-50-01-00)
New U.S.-made proximity sensor with 5m cable. Works with 5m Proximitor systems. Withstands -51°C to +177°C. 12-month warranty. Ships via FedEx/UPS/DHL.
Complete Specifications
- Part Number: 330702-00-24-50-01-00
- Code Breakdown:
- 00: 0″ unthreaded length
- 24: 2.4″ case length
- 50: 5.0m cable (16.4 ft)
- 01: Mini ClickLoc® connector
- 00: No agency approvals
- Electrical: 7.2Ω ±0.8Ω resistance
- Temp Range: -51°C to +177°C
- Thread: 1/2-20 UNF (0.75″ max)
- Torque: 15.2 N•m recommended
- Cable Bend: 25.4mm minimum radius
- Weight: 0.17kg (0.37 lbs)
Installation Guide
- For 5m Proximitor systems only
- Finger-tight connector torque (max 0.565 N•m)
- Avoid temperatures below -34°C to protect seals
- Works with 3300 XL monitors
What’s Included
- Probe with 5m cable
- Connector protector
- 12-month quality guarantee
Technical Questions
- Can I use this with 9m systems?
- No, designed only for 5m Proximitor setups
- Is the O-ring replaceable?
- Yes, uses standard Viton® O-rings
- What’s the cable material?
- FEP-insulated triaxial (75Ω)
- Can it handle steam environments?
- Yes, rated for industrial conditions
- Is calibration needed?
- Pre-calibrated at factory
