Description
Bently Nevada 3300 XL Proximity Probe: Armored 9m Industrial Sensor
High-precision vibration probe with armored cable for harsh environments. Download full specs: [Get Probe Manual]
Product Configuration
330702-00-24-90-01-05 │ ├── 330702 = 3300 XL 11mm Armored Probe ├── 00 = 0.0" Unthreaded Length ├── 24 = 2.4" Case Length ├── 90 = 9.0m Cable ├── 01 = Mini ClickLoc Connector └── 05 = Multiple Approvals
Technical Specifications
- Thread Size: 1/2-20 UNF
- Max Torque: 400 in-lb
- Bend Radius: 25.4mm (1.0″)
- Resistance: 8.5Ω ±1.1Ω
- Weight: 0.17kg (0.37lb)
- Seal Material: Viton O-ring
Installation Guide
- Recommended torque: 133 in-lb
- Max thread engagement: 0.75″
- Keep bends >1″ radius
- Use provided connector protector
Order & Support
- ⏱️ Ships same day from USA
- ???? FedEx/UPS/DHL options
- ???? 12-month probe warranty
Expert FAQ
- Q: Can I cut the armored cable?
A: No – will void warranty and calibration - Q: Is the O-ring replaceable?
A: No – sealed unit - Q: Minimum installation temperature?
A: -30°F to prevent seal damage - Q: Compatible with all 3300 monitors?
A: Yes – standard 3300 XL output - Q: Waterproof rating?
A: IP67 when properly installed
Note: For torque specs and installation diagrams: [Download Engineering Docs]
