11 mm Proximity Probes Bently Nevada 330707-00-10-90-12-00

Description

Bently Nevada 3300 XL 11mm Proximity Probe – High-Performance Vibration Monitoring

Ensure precise machinery health monitoring with the Bently Nevada 3300 XL 11mm Proximity Probe. Designed for durability and accuracy, this probe detects vibration and position changes in rotating equipment. Ideal for industrial applications requiring reliability in harsh conditions.

Technical Data

• Brand: Bently Nevada
• Model: 3300 XL 11mm Proximity Probe
• Part No.: 330707-00-10-90-12-00
• Thread: 5/8-18 UNF
• Cable Length: 9.0 meters (29.5 ft)
• Connector: Miniature coaxial ClickLoc
• Probe Resistance: 8.5 ± 1.1 ohms
• Operating Temp: -51°C to +177°C
• Max Torque: 45.2 N•m (400 in•lb)

Full Suffix Breakdown (330707-00-10-90-12-00)

• 330707 – 3300 XL 11mm Probe, 5/8-18 UNF thread
• 00 – Unthreaded length: 0 in
• 10 – Case length: 1.0 in
• 90 – Cable length: 9.0 meters
• 12 – Miniature coaxial ClickLoc connector, FluidLoc cable
• 00 – No agency approval required

Installation & Maintenance

• Recommended torque: 15.2 N•m (133 in•lb)
• Max thread engagement: 0.938 in
• Connector torque: Finger tight (max 0.565 N•m)
• Min bend radius: 25.4 mm (1.0 in)

Compatibility & Applications

• Works with Bently Nevada 3300 monitoring systems
• Used in turbines, compressors, pumps, and motors
• Detects shaft vibration, eccentricity, and position

Certifications & Shipping

• 12-month warranty
• Shipping: FedEx, UPS, DHL
• Weight: 0.17 kg

FAQ

• Q: Can this probe handle high-pressure environments?
  A: The probe seals differential pressure but is not pressure-tested by default. Contact us for custom testing.
• Q: Is the cable armored?
  A: No, this model has an unarmored FluidLoc cable.
• Q: What’s the minimum operating temperature?
  A: -51°C, but prolonged exposure below -34°C may affect the seal.
