Description
Schneider Electric 140CPU53414: Advanced Control Processor
High-Speed Industrial Automation
Modicon Quantum 140CPU53414 Unity Processor with 100 MHz clock speed and 2972 kB RAM. Features 10-year lithium battery and robust networking capabilities. New in factory packaging.
Performance Specifications
Technical Specifications
- Brand: Schneider Electric
- Model: 140CPU53414
- I/O Capacity:
- Local: 64 inputs/64 outputs
- Remote: 500 inputs/500 outputs
- Network Capacity: 63 drops/network
- Watchdog Timer: 250 ms
- Battery: Lithium 1.2Ah (10-year life)
- Certifications: CE Marked
System Architecture
- Remote Networks: 2
- Distributed Networks: 3
- Max Remote Drops: 31
- Control Switch: Key-operated selector
Installation Guide
Requires 1250 mA bus current. Use key switch for mode selection. Ensure ambient temperature 0-60°C for optimal clock accuracy. Mount in standard Quantum rack.
Compatibility
Works with Modicon Quantum I/O modules. Compatible with Unity Pro software. Supports distributed and remote I/O configurations.
Packaging Options
| Package Type | Units | Dimensions (cm) | Weight |
|---|---|---|---|
| PCE (Single Unit) | 1 | 31.7 x 16.8 x 5.3 | 701 g |
| S03 (Bulk Pack) | 7 | 40 x 30 x 30 | 5.377 kg |
| S04 (Pallet Pack) | 21 | 40 x 30 x 30 | 5.375 kg |
Warranty & Shipping
12-month manufacturer warranty. Ships via FedEx, UPS, DHL in protective packaging. Tracking included.
FAQ
Q: Battery replacement procedure?
A: Hot-swappable lithium battery (420 µA during replacement)
Q: Maximum network distance?
A: Supports remote I/O up to 4,500 meters (with repeaters)
Q: Real-time clock accuracy?
A: Maintains ±8 seconds/day at 0-60°C operating range
Q: Programming environment?
A: Unity Pro software (version 11.0 or higher recommended)
