Schneider Electric 140DAO84210 Discrete Output Module
The 140DAO84210 delivers reliable AC output control for industrial systems. This Modicon Quantum module handles 16 outputs with 83-253V AC range. Perfect for heavy-duty applications. The 140DAO84210 ensures precise control and robust performance.
Key Benefits
• 16 discrete outputs for multiple devices
• Wide voltage range: 83-253V AC
• Fast response: 0.5ms switching
• Four protection groups with separate fuses
• LED status indicators for all channels
• Industrial-grade durability
• Easy integration with Quantum systems
Technical Specifications
Brand: Schneider Electric
Model: 140DAO84210
Series: Modicon Quantum
Output Type: AC Discrete
Number of Outputs: 16 channels
Output Voltage: 83-253V AC
Max Current per Output: 4A RMS
Total Module Current: 16A RMS
Response Time: 0.5ms max
Surge Current: 30A (1 cycle)
Bus Current: 350mA
Fuse Protection: 5A per group
Operating Temperature: 0°C to 60°C
Storage Temperature: -40°C to 85°C
Humidity: 95% non-condensing
Weight: 0.99 lbs (0.45 kg)
Certifications: cUL, FM Class 1 Div 2
Protection Features
• 5A fuse protection per channel group
• RC filter for noise suppression
• Surge current handling up to 30A
• Blown fuse detection
• Loss of field power indication
• ESD protection: 4kV contact, 8kV air
Package Contents
• 1 x 140DAO84210 output module
• Installation documentation
• Quality assurance certificate
Warranty & Shipping
12-month quality warranty provided. Worldwide express shipping via FedEx, UPS, DHL available.
Expert FAQ
How many output groups are there?
Four groups of four outputs each with separate protection.
What is the maximum surge current?
30A for one cycle per point, 45A per group.
Is fuse status monitored?
Yes, blown fuse detection with LED indication.
What voltage ranges are supported?
83-253V AC with 47-63Hz frequency.
How fast is the response time?
0.5ms maximum for both on and off states.
Quick Setup Guide
- Verify AC power supply compatibility
- Mount module in Quantum rack
- Connect field wiring to terminal blocks
- Check all fuse protections are intact
- Verify green ACTIVE LED is lit
- Test each output channel
- Monitor output status LEDs
