Schneider 140DDO36400 – 96-Channel DC Output Module
Description
High-density 96-point output module for Modicon Quantum systems. Controls industrial devices with ultra-fast switching. Ideal for large automation projects.
Technical Data
| Brand | Schneider Electric |
| Model | 140DDO36400 |
| Series | Modicon Quantum |
| Output Channels | 96 points (6 groups) |
| Voltage Range | 19.2-30V DC |
| Response Time | ≤0.1ms |
| Logic Type | Sinking (Negative) |
| Max Current | 0.5A/point | 3.2A/group |
| Protection | Short-circuit & overload |
| Isolation | 500V DC channels-to-bus |
| Operating Temp | 0°C to 60°C (32°F to 140°F) |
Installation
- Mount on Quantum baseplate
- Connect 24V DC power
- Wire outputs in 16-point groups
- Allocate 6 output words in PLC
Diagnostics & Maintenance
- 96 green LEDs (output status)
- Red LED for external faults
- Green LED for bus communication
- Check load current ≤0.5A/point
Packing List
- 140DDO36400 module
- Terminal blocks
- Mounting hardware
Shipping
Worldwide via FedEx, UPS, or DHL. Single unit: 545g (1.2lb). Bulk pack: 7 units.
FAQ
Q: Surge current capacity?
A: 2A (momentary)
Q: Hazardous area certified?
A: Yes – FM Class 1 Division 2
Q: Max altitude for operation?
A: 5000m (16,404 ft)
0.0 Average Rating Rated (0 Reviews)
