Schneider Electric 140DDO84300 – 16-Channel DC Output Module
High-performance output module for industrial automation. Handles 10-60V DC signals with 1ms switching speed. Features robust protection and dual-channel grouping. Ideal for demanding control applications.
???? Technical Specifications
| Brand | Schneider Electric |
| Model | 140DDO84300 |
| Series | Modicon Quantum |
| Output Type | Positive logic (source) |
| Voltage Range | 10-60V DC |
| Max Current | 12A module / 6A group |
| Response Time | 1ms (both directions) |
| Isolation | 2500Vrms (channel-bus) |
Output Performance
- Voltage Drop: <1V @ 2A
- Leakage Current: ≤1mA @ 60V
- Surge Current: 7.5A for 50s
- Load Formula: L(H) = 0.5/(I² × fsw)
- Absolute Max Voltage: 72V permanent
Protection & Safety
- Dual Fuse Protection:
- 8A per group
- 2A per point
- Certifications: UL508, CSA, FM Class 1 Div 2
- ESD Protection: 8kV air / 4kV contact
- EMI Resistance: 10V/m (80-2000MHz)
LED Indicators
- Green: Bus communication (Active)
- Red: External fault (F)
- 16 Green LEDs: Output status
Installation Guide
- Mount in Quantum rack
- Requires 1 output word addressing
- Maintain 5cm clearance for heat dissipation
- Observe group current limits (6A max/group)
Packaging Details
- Output module
- Terminal accessories
- Module Weight: 0.45 kg
- Package Dimensions: 30.91 × 16.33 × 4.73 cm
- Package Weight: 0.45 kg
- GTIN: 3595861000117
FAQ
Q: Current capacity per channel?
A: 2A continuous (fuse-protected)
Q: Switching frequency limit?
A: Determined by load inductance formula
Q: Hazardous area approval?
A: FM Class 1 Division 2 certified
