142238-120-00-CN Bently Nevada Proximity Vibration Cable

Description

Bently Nevada 142238-120-00-CN: 12m Proximity Vibration Probe – Precision Monitoring for Large Machinery

What It Does

A 12m proximity vibration probe for measuring machine movement (like vibration or shaft position). Works with Bently Nevada’s 3300/3300 XL sensors and 170133-140-XX proximitor modules. Ideal for big machines where sensors need to be far from monitors.

Part Number Breakdown (142238-AXX-BXX-CXX)

• A: Total Length – 120 = 12m (39.4ft)
• B: Cable Type – 00 = Standard cable
• C: Approval – CN = Country-Specific

Key Tech Specs

• Measurement Type: Non-contact vibration/shaft position
• Sensitivity: 8mV/μm (±0.5mV/μm)
• Linear Range: ±2mm
• Frequency Response: 5Hz to 10,000Hz
• Operating Temp: -40°C to +150°C (-40°F to +302°F)
• Output Signal: Analog (0-10V DC)
• Cable Resistance: 12m length:
  • Center conductor: 3.0 ± 0.75Ω
  • Shield conductor: 0.9 ± 0.2Ω

Ship via FedEx, UPS, or DHL (3-5 days standard). Request a U.S.A. Certificate of Origin (COO) at checkout for international orders.
