Schneider Modicon 140NOE77110 Quantum Ethernet Module
Industrial Ethernet Communication Solution
Advanced Transparent Ready™ module for Modicon Quantum systems. Features dual Ethernet ports, fiber optic connectivity, and web services for industrial IoT applications. Certified for harsh environments.
Key Technical Specifications
- Dual Interfaces: MT/RJ fiber optic + RJ45 copper
- Speed: 10/100 Mbps auto-negotiation
- Protocols: Modbus TCP, SNMP, HTTP
- Redundancy: Hot standby supported
Enhanced Technical Parameters
| Web Server Class | C20 with FactoryCast |
| Max Connections | 32 simultaneous TCP/IP |
| Data Throughput | 12,000 registers/second |
| Fiber Distance | 2km (multimode), 15km (single mode) |
| Copper Distance | 100m (CAT5e) |
| Diagnostic LEDs | 12 status indicators |
| Power Consumption | 750mA @ 5V DC |
Industrial Application Cases
- Smart Factories: Real-time machine data collection
- Water Treatment: SCADA system integration
- Power Distribution: Grid monitoring and control
- Pharmaceutical: Batch process tracking
Communication Capabilities
- Web Services: Rack viewer, data editor, configuration
- Protocol Support: Modbus TCP, FTP, SNMP, HTTP
- Security: Password protection, IP filtering
- Redundancy: <1s switchover time
Environmental Specifications
| Ingress Protection | IP20 |
| ESD Protection | 8kV air / 4kV contact |
| EMI Resistance | 10V/m (80-1000MHz) |
| Operating Temp | 0°C to 60°C |
| Altitude Rating | 4,500m (14,764ft) |
| Certifications | cUL, UL508, FM Class 1 Div 2 |
Physical Specifications
- Dimensions: Standard Quantum module
- Weight: 0.345kg (0.76lb)
- Connectors: MT/RJ (fiber), RJ45 (copper)
- Mounting: DIN rail or panel
LED Status Indicators
- RUN: Network operational
- FAULT: Module error
- TxAct/RxAct: Data transmission
- LINK: Network connection
- Fduplex: Full duplex mode
Ordering & Shipping
- GTIN: 3595860033932
- Origin: France
- Package Size: 31×16.5×5 cm
- Shipping Weight: 668g
- Delivery: FedEx/UPS/DHL (global)
Frequently Asked Questions
Q: Supported fiber types?
A: Multimode (62.5/125μm) and singlemode (9/125μm)
Q: Web server capabilities?
A: Real-time data monitoring, configuration, diagnostics
Q: Redundancy requirements?
A: Requires paired module and 140CRA93100 controller
Q: Configuration software?
A: Unity Pro with Ethernet configuration package
Q: SNMP functions supported?
A: Traps, MIB-II, custom alarm management
Q: Maximum network nodes?
A: 254 devices per Ethernet segment
