Schneider Electric Analog Input Module – Precision Signal Acquisition
Product Overview
The Schneider 170AAI14000 analog input module delivers high-accuracy signal conversion for industrial control systems. Designed for reliable performance in demanding environments with CE certification.
Critical Technical Specifications
| Parameter | 4-20mA | ±10V/±5V |
|---|---|---|
| Input Impedance | < 0.25 Ω | > 2200 kΩ |
| Accuracy at 25°C | ±0.25% FS | ±0.15% FS |
| Accuracy at 60°C | ±0.45% FS | ±0.25% FS |
| Temp Drift | 60 %oFS/°C | 30 %oFS/°C |
| Update Speed | 25 ms | |
| Isolation | 1780V AC | |
Physical Specifications
- Dimensions: 125mm H × 141.5mm W × 47.5mm D
- Weight: 0.215 kg
- Power Consumption: 5.55 W
- Status Indicators: 16-channel LED monitoring
Environmental Ratings
- Operating Temp: -20°C to +60°C
- Storage Temp: -40°C to +85°C
- Humidity: 5-95% non-condensing
- Vibration: 3g @ 10-150 Hz
Installation Guide
- Mount on DIN rail using top/bottom clips
- Maintain 20mm clearance above/below module
- Use shielded twisted-pair cables
- Ground shield at one end only
- Verify common mode voltage <100V DC
Compatibility
- Modicon Quantum PLC systems
- Unity Pro programming software
- 140CPS11100 power supplies
- 140XBP00200/00300 backplanes
Shipping & Warranty
Global delivery via FedEx, UPS, DHL | 12-month manufacturer warranty | Ships from EU/US warehouses
FAQ
Q: What cable length is supported?
A: Up to 100m with proper shielding – use 18AWG twisted pair
Q: Can it handle 0-10V sensors?
A: Yes – configure for ±10V range in Unity Pro software
Q: What do the LED indicators show?
A: Green: channel active | Red: wiring fault | Off: channel disabled
Q: Is calibration required?
A: Factory calibrated – field recalibration not needed
Q: Compatible with 140ACI04000?
A: Yes – both use same backplane and power requirements
