172103-01 Bently Nevada 3500/65 RTD/Isolated Tip TC I/O Module

Description

Bently Nevada 3500/65 RTD/Isolated Tip TC I/O Module (172103-01)

The 172103-01 is a **16-channel I/O module** for the 3500 Series, supporting **RTD and isolated thermocouple inputs** with high accuracy and isolation. Designed for precision temperature monitoring in harsh industrial environments, it ensures reliable data acquisition for critical machinery protection.

Technical Data

• Brand: Bently Nevada
• Part No.: 172103-01
• Suffix Breakdown:
  • 172103: Base Model (3500/65 RTD/TC Module)
  • -01: Configuration Code (16 Channels)
• Input Types: RTD (Pt100, Pt250, Pt500, Pt1000) / TC (J, K, T, E, N, R, S, B)
• Temperature Range:
  • RTD: -200°C to +850°C
  • TC: -270°C to +1820°C
• Accuracy: ±0.05% (RTD) / ±0.1% (TC)
• Resolution: 0.1°C (0.18°F)
• Update Rate: 1 second per channel (configurable)
• Isolation: Channel-to-channel & channel-to-ground
• Power: 3500 rack-powered (no external supply)
• Operating Temp: -30°C to +65°C (-22°F to +149°F)

Features

• Supports **16 RTD or thermocouple sensors** simultaneously
• Wide compatibility with industry-standard RTD/TC types
• High isolation reduces signal interference

Installation

• Rack Integration: Compatible with all 3500 Series racks
• Wiring: Pre-terminated connectors for quick setup

Certifications

• Complies with global industrial standards (e.g., ATEX, IECEx on request).

Applications

Deployed in nuclear power plant cooling systems to monitor reactor coolant temperatures. Case Study: Integrated into a refinery’s cracking unit, enabling real-time thermal profiling and reducing downtime by 22%.

Contact: For pricing or technical details, email sales@ubestplc.com.
