Description
Bently Nevada RTD Temperature Monitor
3500/60-01-02 Precision industrial temperature sensing with 4-20mA output and hazardous area compliance for critical process control.
Core Specifications
- Input Type: 100Ω Platinum RTD (3-wire)
- Range: -200°C to +850°C (-328°F to 1562°F)
- Accuracy: ±1°C @ 25°C (±0.15% of reading)
- Resolution: 0.1°C (0.18°F)
System Integration
- Analog Output: 4-20mA (24V loop powered)
- Communication: Modbus RTU @ 9600 baud
- Power Supply: 24VDC ±10%
- Isolation: 1500Vrms input-to-output
Suffix Decoder for 3500/60-01-02
- 3500/60: Temperature Monitoring Platform
- -01: RTD/TC Non-isolated I/O Module
- -02: ATEX/IECEx/CSA (Class I Zone 2)
Physical Dimensions
| Component | Dimensions | Weight |
|---|---|---|
| Monitor Module | 241.3 x 24.4 x 241.8mm | 2.0 lb (0.91kg) |
| I/O Module (Standard) | 241.3 x 24.4 x 99.1mm | 1.0 lb (0.45kg) |
Certifications
- ATEX: II 3G Ex ec IIC T4 Gc
- IECEx: Ex ec IIC T4 Gc
- CSA: Class I Div 2 Groups A-D
Industrial Applications: Boiler temperature monitoring • Chemical reactor control • Gas turbine exhaust measurement
Contact sales@ubestplc.com for DIN-rail mounting kits.
