1734-ARM Allen-Bradley Address Reserve Module | Point I/O Slot Position Saver

Description

Allen-Bradley 1734-ARM Address Reserve Module | Point I/O Slot Saver

Plan for future expansion with the practical 1734-ARM module. This address reserve module maintains your I/O numbering scheme when modules are temporarily removed.

Installation Resources

• Complete installation and configuration guide available
• Learn how to properly use address reservation
• Download Point I/O Manual Here

Technical Specifications

• Brand: Allen-Bradley
• Model: 1734-ARM
• Series: Point I/O
• Module Type: Address Reserve Module
• POINTBus Current: 75mA @ 5V DC
• Power Dissipation: 0.375W
• Thermal Dissipation: 1.3 BTU/hour maximum
• Status Indicators: Green/red network and module LEDs
• Operating Temperature: -4°F to 131°F (-20°C to 55°C)
• Humidity Rating: 5% to 95% non-condensing
• Required Base: 1734-TB or 1734-TBS wiring base
• Key Position: Any position (not designated)
• Mounting: DIN rail

Compatibility Information

• Works with all Point I/O systems
• Requires 1734-TB or 1734-TBS wiring base
• Compatible with all slot positions
• No special configuration needed

Frequently Asked Questions

• Q1: What is the main purpose of the 1734-ARM module?
• A1: The 1734-ARM reserves slot addresses and maintains I/O numbering when modules are temporarily removed from the system.
• Q2: Can this module communicate I/O data?
• A2: No, it doesn’t communicate data – it only reserves the physical slot address for future use.
• Q3: Does the 1734-ARM require a specific key position?
• A3: No, it can be installed in any slot with any key position, providing maximum flexibility.
• Q4: What base unit is required for this module?
• A4: It requires either a 1734-TB or 1734-TBS wiring base assembly for installation.
• Q5: When should I use this address reserve module?
• A5: Use it when you need to remove a module temporarily but want to maintain the same address for when you reinstall it later.

Shipping & Warranty

We ship worldwide via FedEx, UPS, and DHL. This product includes our 12-month warranty against defects.
