Allen-Bradley 1756-IB16 Digital Input Module – Industrial Automation Powerhouse
⚡ Core Specifications
Brand: Allen-Bradley
Model: 1756-IB16
Inputs: 32 DC sink (12-24VDC)
Speed: 1ms ON/OFF response
Certifications: CE, UL, RoHS
???? Technical Highlights
• 10-31.2VDC operating range
• 2mA min / 10mA max current
• 5.1W power dissipation
• 21.1 BTU/hr thermal output
• Compatible with 1756-TBCH/TBS6H terminals
???? Real-World Applications
Auto Assembly: Monitors 200+ robotic sensors
Packaging Lines: Tracks 50k boxes/hour production
Smart Buildings: Controls HVAC & lighting systems
???? Installation Guide
1. Install in ControlLogix chassis
2. Connect 24VDC power (±10%)
3. Wire inputs via terminal blocks
4. Configure in Studio 5000
5. Verify LED status indicators
⚠️ Safety Notes
• Use 18AWG shielded cables
• Maintain 50mm airflow clearance
• Ground chassis to <1Ω resistance
• Never exceed 31.2VDC input
???? Global Shipping
FedEx Industrial: 3-5 work days
DHL Express: 2-4 work days
UPS Worldwide: 4-7 work days
???? Warranty & Support
12-month replacement warranty
24/7 technical support via phone/email
