1756-LSP Allen-Bradley | Safety Partner Module – Redundant Control

Description

Allen-Bradley 1756-LSP: GuardLogix Safety Partner Module

The Allen-Bradley 1756-LSP is a safety partner module for GuardLogix systems. It works with primary controllers to provide safe operation in critical applications.

Complete Technical Specifications

• Brand: Allen-Bradley / Rockwell Automation
• Full Model: 1756-LSP
• Module Type: Safety Partner Module
• Compatible With: 1756-L61S, L62S, L63S controllers
• Safety Memory: 1MB to 3.75MB (matches primary controller)
• Power Use: 3.5W, 1200mA @ 5V, 14mA @ 24V
• Installation: Installs right of primary controller
• Chassis Compatibility: 1756-A4, A7, A10, A13, A17
• Operating Temp: 0 to 60°C (32 to 140°F)
• Battery: 1756-BA2 lithium battery
• Isolation: 30V continuous
• Weight: 0.7 lbs (0.32 kg)

Compatibility Information

The 1756-LSP works with GuardLogix L61S, L62S, and L63S controllers. It must be installed in the slot immediately right of the primary controller.

Installation Guide

Install directly to the right of compatible primary controller. Requires proper chassis and power supply.

Download Product Manual

• Complete installation guide
• Safety configuration instructions
• Compatibility information
• Get full documentation: 1756 ControlLogix Manual

Professional FAQ

• What controllers does it work with? – L61S, L62S, and L63S primary controllers
• Where should it be installed? – In the slot immediately right of the primary controller
• What safety level does it support? – Up to SIL 3 safety requirements
• Does it have its own memory? – No, it uses the primary controller’s memory
• What battery does it use? – 1756-BA2 lithium battery

Shipping & Warranty

We ship worldwide via FedEx, UPS, and DHL. Full 12-month warranty included.

Package Includes

• One 1756-LSP safety partner module
• Installation guide
• (Battery sold separately)
