1756-OA16I Allen-Bradley ControlLogix AC Output Module | Fast Delivery

Description

Allen-Bradley 1756-OA16I ControlLogix AC Output Module

Power your AC devices with the Allen-Bradley 1756-OA16I. This robust 1756-OA16I module offers 16 individually isolated AC outputs. It handles high voltages up to 265V AC, making it ideal for industrial lighting, heaters, and motor controls.

Key Benefits

• 16 isolated outputs for AC power control
• High voltage range 74-265V AC operation
• Strong current rating 2A per point @ 30°C
• Works with global AC voltages 47-63Hz
• Built for heavy-duty industrial use

Technical Specifications

Brand: Allen-Bradley
Model: 1756-OA16I
Series: ControlLogix
Type: AC Output Module
Outputs: 16 individually isolated
Voltage Range: 74-265V AC
Frequency: 47-63 Hz
Current Per Point: 2A @ 30°C, 1A @ 60°C
Total Current: 5A @ 30°C, 4A @ 60°C
Response Time: 9.3ms @ 60Hz, 11ms @ 50Hz
Leakage Current: 3mA per point
Power Dissipation: 5.5W @ 60°C
Inrush Capacity: 20A for 43ms
Isolation: 250V continuous
Terminal Blocks: 1756-TBCH, 1756-TBS6H
Backplane Current: 300mA @ 5.1V
Operating Temp: 0 to 60°C

Package & Support

• One 1756-OA16I AC output module
• 12-month reliability warranty
• Global shipping via FedEx, UPS, DHL

Resources & Documentation

• Installation guide
• Wiring instructions
• Application examples
• Download complete technical manual here
