Allen-Bradley 1756-OG16: 16-Point TTL Output Module
The Allen-Bradley 1756-OG16 is a digital DC output module designed for ControlLogix systems. It provides sixteen 5V TTL outputs for precise control applications. This 1756-OG16 module is ideal for interfacing with low-voltage digital devices and logic circuits.
Complete Product Information
- Access detailed technical specifications
- View wiring diagrams and installation guides
- Download the full product manual here
Technical Specifications
Brand: Allen-Bradley
Model: 1756-OG16
Type: Digital DC Output Module
Output Points: 16 points
Output Type: 5V TTL Source
Voltage Range: 4.5-5.5V DC
Point Current: 24mA maximum per point
Module Current: 384mA maximum total
Response Time: 450μs OFF-ON, 700μs ON-OFF
Voltage Drop: 0.4V typical
Leakage Current: 0.1mA maximum
Power Consumption: 210mA @ 5.1V
Isolation: 50V continuous
Installation & Usage
This module installs in any ControlLogix chassis. It requires a removable terminal block (1756-TBNH or 1756-TBSH) for connection. The 1756-OG16 is perfect for driving low-power TTL-compatible devices and logic circuits.
Warranty & Support
We provide a comprehensive 12-month warranty on this product. Our technical support team is available for installation guidance and troubleshooting.
Shipping Options
We ship worldwide using FedEx, UPS, and DHL for reliable and fast delivery service.
Frequently Asked Questions
- What does TTL output mean?
TTL (Transistor-Transistor Logic) outputs provide 5V signals compatible with most digital logic circuits and devices. - What is the maximum current per output?
Each output can handle up to 24mA, suitable for driving LEDs, small relays, and logic inputs. - How fast can the outputs switch?
The outputs switch in 450 microseconds from OFF to ON and 700 microseconds from ON to OFF. - What is the total module current capacity?
The module can deliver up to 384mA total across all 16 outputs combined. - Is this module suitable for high-noise environments?
Yes, it features good noise immunity and is designed for reliable operation in industrial settings.
