Allen-Bradley 1762-OV32T: 32-Point Sinking Output Module
The Allen-Bradley 1762-OV32T delivers high-density output control for MicroLogix systems. This Rockwell Automation module provides thirty-two sinking outputs in a compact design.
Technical Specifications & Performance Data
- Brand: Allen-Bradley
- Model: 1762-OV32T
- Module Type: 24VDC Sinking Output
- Number of Outputs: 32 points
- Output Configuration: Sinking (NPN)
- Operating Voltage Range: 10.2-26.4V DC
- Heat Dissipation: 2.7 kW at 26.4V DC
- Backplane Current Draw: 175 mA at 5V DC
- Output Current per Point: 0.5A maximum
- Total Module Current: 8.0A maximum
- Response Time: 1 ms maximum
- Isolation Voltage: 1500V AC
Environmental Ratings & Protection
- Operating Temperature: -20 to 60°C (-4 to 140°F)
- Storage Temperature: -40 to 85°C (-40 to 185°F)
- Relative Humidity: 5% to 95% non-condensing
- Maximum Altitude: 2000 meters (6562 feet)
- Enclosure Rating: IP20 for general purpose use
- Pollution Degree: 2 (dusty environments)
- Vibration Resistance: 5G at 10-500 Hz
- Shock Resistance: 25G operational rating
Physical Dimensions & Shipping
- Module Dimensions: 90 × 40.4 × 87 mm (3.54 × 1.59 × 3.43 in)
- Shipping Weight: 200 grams (7.05 ounces)
- Package Includes: One 1762-OV32T module
- Shipping Methods: FedEx, UPS, DHL available
- Delivery Time: Express options available
Comparison With Related Products
- The 1762-OV32T offers 32 sinking outputs
- Compare with the 1762-L24AWA programmable controller
- Or the 1762-L24BWA relay output PLC
- This module provides high-density sinking output capability
