Allen-Bradley 1769-ARM Address Reserve Module
The Allen-Bradley 1769-ARM is a special module that saves space in your control system for future expansion. It holds a place in your rack so you can add new modules later without changing your program. This smart planning tool helps avoid downtime during system upgrades.
Technical Specifications
Brand: Allen-Bradley
Model: 1769-ARM
Module Type: Address Reserve Module
Current Draw: 60 mA @ 5.1V DC
Heat Dissipation: 0.3 Watts max
Power Supply Distance: 8 modules max from power supply
Operating Temperature: 0°C to 60°C (32°F to 140°F)
Storage Temperature: -40°C to 85°C (-40°F to 185°F)
Dimensions: 118mm H x 35mm W x 87mm D (4.65″ x 1.38″ x 3.43″)
Weight: 0.62 lbs (0.28 kg)
Mounting: DIN Rail or Panel
Installation Guide
Install the module in any slot up to 8 positions away from the power supply. Use standard DIN rail or panel mounting methods. Ensure proper locking mechanism engagement.
FAQ
- 1. What does the 1769-ARM module do?
It reserves a slot in your control system for future module additions. - 2. Can I use it with MicroLogix controllers?
Yes, it works with both CompactLogix and MicroLogix 1500 systems. - 3. How much power does it use?
It draws only 60mA at 5.1V DC with minimal heat generation. - 4. What is the maximum distance from power supply?
It can be installed up to 8 modules away from the power supply. - 5. Does it require special configuration?
No, it operates without complex setup or configuration files.
Packaging & Warranty
Package Includes: One (1) Allen-Bradley 1769-ARM Address Reserve Module.
This product includes a 12-month warranty for your protection.
