Description
Allen-Bradley 1785-L80C15 ControlNet PLC-5 Processor
The Allen-Bradley 1785-L80C15 is a powerful and versatile ControlNet PLC-5 programmable logic controller from Rockwell Automation. It is built for large, complex industrial applications, offering robust communication and high I/O capacity. This processor handles demanding automation tasks with ease.
Technical Specifications
- Brand: Allen-Bradley / Rockwell Automation
- Model: 1785-L80C15
- Controller Type: PLC-5/80C
- Max Total I/O: 3072 (any mix)
- User Memory: 100 Kilowords
- Communication Ports: ControlNet (x2), DH+, RIO, Serial, DH (via 1785-KA)
- Battery: 1770-XYC (Battery-Backed RAM)
- Program Scan Time: 0.5 ms per K word (bit logic)
- I/O Chassis Support: Bulletin 1771, 1794, 1746, 1791
- Operating Temperature: 0 to 60 °C (32 to 140 °F)
Installation & Compatibility
- Install in the left-most slot of a 1771-A1B, -A2B, -A3B, -A3B1, or -A4B chassis.
- Uses keying bands between pins 40-42 and 54-56 for correct installation.
- Compatible with a wide range of Allen-Bradley I/O modules including 8-, 16-, and 32-point cards.
- Supports 2-slot, 1-slot, and 1/2-slot hardware addressing for configuration flexibility.
Packaging & Shipping
- This product ships with the 1785-L80C15 processor unit.
- We ship globally using reliable carriers like FedEx, UPS, and DHL.
