200152-15-10 Accelerometer Interface Cable: Reliable Signal Transmission for Vibration Monitoring
Bently Nevada’s premium accelerometer cable features enhanced coupling nuts and IP67 sealing for critical machinery monitoring. Designed for permanent installations in harsh industrial environments.
TECHNICAL SPECIFICATIONS
| Part Number | 200152-15-10 |
| Length | 15 meters |
| Temperature Range | -55°C to +121°C (-67°F to +250°F) |
| Bend Radius | 73.7 mm (2.9 in) |
| Conductors | 4x 22 AWG with drain wire |
| Shielding | Braided (85% coverage) |
| Seal Rating | IP67 when connected |
| Jacket Material | PVC |
PART NUMBER DECODER
200152 → Accelerometer interface cable
-15 → 15 meter length
-10 → Enhanced coupling nut
INSTALLATION CRITICALS
- Thermal curing: Allow 24 hrs after installation before power-on
- Cold weather: Avoid flexing below -20°C (-4°F)
- Bending: Maintain >73.7mm radius at all points
CONNECTION SPECIFICS
| Feature | Accelerometer End | Monitor End |
| Connector | Molded with DC4 compound | Bare wires |
| Coupling Nut | Enhanced grip design | N/A |
| Sealing | IP67 protection | Requires termination |
INDUSTRIAL APPLICATIONS
- Paper Mills: Withstands steam/humidity with IP67 seal
- Offshore Platforms: Salt spray resistance via nickel-plated nuts
- Power Plants: -55°C cold start capability
- Mining Equipment: Braided shield prevents EMI from heavy machinery
PACKAGE CONTENTS
- 1x 15m cable assembly
- Installation guide
- 12-month warranty card
SHIPPING
Global delivery via FedEx, UPS, DHL. Ships in crush-proof packaging.
FAQ
Q: Why 24-hour cure time?
A: DC4 compound needs time to form moisture barrier after thermal cycling.
Q: Can I use in food processing plants?
A: Yes – PVC jacket resists oils and cleaning chemicals.
Q: Difference between -10 and standard nuts?
A: Knurled surface provides 40% better grip with gloves.
Q: Minimum installation temperature?
A: -20°C (-4°F) if cable remains stationary after installation.
Q: Compatible with non-Bently accelerometers?
A: Yes – standard IEPE interface works with most 4-pin sensors.
