Bently Nevada 3300 NSv Proximity Probe with FluidLoc Cable
Product Highlights
New factory-sealed 330903-00-03-05-11-05 featuring 30mm case length and FluidLoc cable. Designed for harsh environments with M8X1 threading. Includes 12-month warranty.
Model Suffix Breakdown
- Base Model: 330903
- Unthreaded Length: -00 → 00 mm
- Case Length: -03 → 30 mm
- Cable Length: -05 → 0.5 meter
- Connector Type: -11 → ClickLoc with FluidLoc cable
- Approvals: -05 → Multiple agency certifications
Technical Specifications
- Electrical Performance:
- Frequency response: DC to 10 kHz (±3dB)
- Probe resistance: 4.0Ω ±0.5Ω at 0.5m
- Cable capacitance: 69.9 pF/m (typical)
- Measurement Accuracy:
- Scale factor: 7.87 V/mm (±12.5%)
- Deviation: < ±0.06 mm over 1.5mm range
- Linearity: ±5% of full scale
- Environmental Rating:
- Operating temp: -52°C to +177°C
- Fluid resistance: Enhanced chemical protection
- Sealing: Viton O-ring pressure seal
- Mechanical Properties:
- Case material: 304 stainless steel
- Tip material: Polyphenylene sulfide (PPS)
- Bend radius: 25.4 mm minimum
Installation Guide
- Optimal gap: 1.0 mm (40 mils) from target
- Torque specification: 5.1 N•m recommended (45 in•lb)
- Thread engagement: Max 12mm for M8x1 threading
- Wiring: Use shielded triad cable (max 305m)
FluidLoc Cable Advantages
- Superior chemical resistance vs standard cables
- Enhanced protection in wet environments
- Ideal for process compressors and oil applications
Compatible Models Comparison
| Model | Case Length | Cable Type | Details |
|---|---|---|---|
| 330903-00-05-05-02-00 | 50mm | Standard | Basic environmental protection |
| 330903-00-03-05-12-00 | 30mm | Armored | Stainless steel armored cable |
| This Model: 330903-00-03-05-11-05 | 30mm | FluidLoc | Enhanced chemical resistance |
Package & Shipping
- Factory-sealed with protective caps
- 12-month warranty documentation
- Global shipping via FedEx, UPS, DHL (express options available)
