Bently Nevada 3300 NSv Probe – Industrial-Grade Vibration Monitoring
Product Overview
Brand new 330903-00-05-70-02-00 proximity probe with M8X1 threading and 7-meter standard cable. Features enhanced chemical resistance for harsh environments and direct compatibility with 3300 RAM systems. Ships via FedEx/UPS/DHL with 12-month warranty.
Key Specifications
- Full Model Breakdown:
• 330903: Base model
• 00: Unthreaded length = 00mm
• 05: Case length = 50mm
• 70: Cable length = 7.0m
• 02: Connector = Miniature ClickLoc
• 00: Agency approval = Not required - Critical Measurements:
– Range: 1.5mm (60 mils)
– Accuracy: ±0.06mm max deviation
– Output: -1 to -13 Vdc
– Response: 0-10 kHz frequency
– Temp Range: -52°C to +177°C
Installation Details
- – Set gap at 1.0mm (40 mils)
- – Apply finger tight torque (max 0.56 N•m)
- – Keep 25.4mm bend radius
- – Use minimum Ø13mm targets
- – Max thread engagement: 12mm
Cable & Connection Data
- – Cable type: Standard (suffix 02)
- – Resistance: 5.9Ω ±0.9Ω
- – Length: 7.0 meters
- – Connector: ClickLoc coaxial
- – Field wiring: Up to 305 meters
Material & Construction
- – Tip: PPS plastic
- – Case: 304 stainless steel
- – Seal: Viton O-ring
- – Cable: 75Ω coaxial with FEP insulation
Shipping & Support
- – New in factory packaging
- – 12-month warranty
- – Global delivery via FedEx/UPS/DHL
Common Questions
- Q: Difference between FluidLoc and standard cable?
A: Standard cable (suffix 02) vs. FluidLoc (suffix 12) – choose based on chemical exposure - Q: How does 50mm case length affect installation?
A: Provides deeper mounting – check clearance in housing - Q: Pressure rating for this probe?
A: Not rated – contact for custom pressure testing - Q: Compatible with 190 series monitors?
A: Yes – electrically matches previous probes
