Bently Nevada 3300 XL 11mm Proximity Probe: Precision Vibration Monitoring
Description
Industrial-grade 11mm proximity probe for machinery health monitoring. Made in USA with Viton O-ring seal. Measures vibration/displacement in turbines, compressors, and motors.
Key Features
- Tip Material: Polyphenylene sulfide (PPS)
- Case Material: AISI 304 stainless steel
- Seal: Viton O-ring (withstands -51°C to +177°C)
- Warning: Avoid below -34°C to prevent seal damage
Technical Specifications
- Brand: Bently Nevada
- Model: 3300 XL 11mm Probe
- Full Suffix: 330701-00-24-10-11-05
- Cable: 1.0 meter FluidLoc FEP triaxial (75 Ω)
- Thread: 1/2-20 UNF (Max engagement: 0.75 in)
- Connector: Miniature coaxial ClickLoc
- Resistance: 5.9Ω ±0.5Ω (center to outer conductor)
- Bend Radius: 25.4 mm (1.0 in)
Installation Guide
- Case Torque: 15.2 N•m (133 in•lb) recommended | 45.2 N•m (400 in•lb) max
- Connector Torque: Finger tight | Max 0.565 N•m (5 in•lb)
- Pressure testing not included – contact for custom requests
Compatibility
Works with Bently Nevada 3300 XL monitoring systems. Compatible with Miniature ClickLoc interfaces.
Certifications
Multiple international agency approvals (Option 05).
Package & Warranty
- Probe unit with connector protector
- Shipping weight: 0.17 kg
- 12-month warranty
Shipping
FedEx, UPS, or DHL express delivery.
FAQ
- Q: Cable length options?
A: 1m (included), 5m, or 9m - Q: Pressure rating?
A: Contact for custom pressure testing - Q: Thread alternatives?
A: M16x1.5 version available (24mm max engagement)
