Bently Nevada 3300 NSv Probe 330904-08-15-50-01-00

Description

Bently Nevada 3300 NSv Probe: Advanced Vibration Sensing Solution

Core Benefits

• New factory-sealed with 12-month warranty
• 150mm stainless steel case for tough environments
• 5-meter cable with protective connector
• Works with 3300 RAM systems (no upgrade needed)

Complete Product Identification

• Brand: Bently Nevada
• Full Model: 330904-08-15-50-01-00
• Suffix Breakdown:
  • -08- = 80mm unthreaded section
  • -15- = 150mm overall case
  • -50- = 5.0 meter cable
  • -01- = ClickLoc connector with protector
  • -00- = No agency approval needed

Critical Specifications

• Measurement Range: 0.25–1.75mm (10–70 mils)
• Accuracy: ±0.06mm deviation
• Temp Resistance: -52°C to +177°C
• Output Signal: -1 to -13 Vdc
• Response Speed: 0-10kHz frequency
• Cable Resistance: 5.3Ω ±0.7Ω
• Bend Radius: Minimum 25.4mm

Key Differentiators

• 30% longer case (150mm vs standard 100mm)
• Connector protector prevents damage during install
• Chemical-resistant PPS tip material
• Works on shafts down to 8.9mm diameter

Shipping & Support

• Delivery: FedEx/UPS/DHL (2-5 days worldwide)
• Warranty: 12 months full coverage
• Package: Factory sealed box with docs

Technical FAQ

• Q: What’s different about the -01 connector option?
  A: Includes protective cover for damage prevention
• Q: Maximum pressure rating?
  A: Not rated – uses Viton seal for differential pressure
• Q: Can I use this in food processing plants?
  A: Yes – stainless steel and chemical-resistant materials
• Q: Minimum shaft speed for accurate readings?
  A: Works at any speed – measures position not rotation
• Q: Replacement for 3300 RAM probes?
  A: Direct swap – same electrical and mechanical specs
