3300 XL 8 mm Reverse Mount Probe Bently Nevada – 330106-05-30-10-12-00

Description

Bently Nevada 3300 XL 8mm Reverse Mount Probes – 1.0m Industrial Vibration Sensor

Key Product Overview

Engineered for precision vibration monitoring, the Bently Nevada 3300 XL 8mm Reverse Mount Probe (Product No.: 330106-05-30-10-12-00) combines compact design with robust performance. Made in the U.S.A., it’s ideal for space-constrained industrial setups.

Core Technical Specs

• – Model & Suffix: 3300 XL 8mm Reverse Mount (330106-05-30-10-12-00).
• Suffix details: 10 = 1.0m total length; 12 = Miniature ClickLoc + FluidLoc cable; 00 = No agency approval.
• – Electrical: 7.59 ± 0.50Ω DC resistance (1.0m length); 75Ω triaxial cable (FEP/PFA insulation options).
• – Materials: Probe tip – Polyphenylene sulfide (PPS); Case – AISI 303/304 stainless steel.
• – Dimensions: M10x1 thread (max 15mm engagement); Weight – 323g/m.
• – Strength: 330N tensile strength (probe case to lead); 270N at lead-to-cable connectors.

Temperature & Environment

• – Standard Use: -52°C to +177°C (-62°F to +350°F).
• – Extended Range: Probe tip (-52°C to +218°C); Cable/connector (-51°C to +260°C).
• – Humidity: ≤3% ASF change at 93% humidity (IEC 68-2-3, 56 days).

Cable & Connector Details

• – Standard Cable: FEP-insulated, available in 0.5/1/1.5/2/3/5/9m lengths.
• – Extended Temp Cable: PFA-insulated, lengths: 0.5/1/1.5/2/5/9m.
• – FluidLoc Option (12): Added liquid protection, but often unnecessary with probe sleeve. Use only for high-moisture applications.

Installation Guidelines

• – Thread size: M10x1 (max 15mm engagement).
• – Avoid temperatures below -34°C (-30°F) to prevent pressure seal damage.
• – Connect via Miniature ClickLoc for stable signal transmission.

Warranty & Shipping

• – 12-month warranty covers manufacturing defects.
• – Shipped via FedEx, UPS, or DHL (trackable worldwide).

Typical Applications

Suitable for small-scale machinery: pumps in water treatment plants, fans in HVAC systems, and compressors in food processing facilities.

New FAQs

• – Q: What’s the FluidLoc cable for?
• A: It adds extra liquid resistance but is rarely needed with the probe sleeve. Only order if your setup has frequent liquid exposure.
• – Q: Can I use a 1.0m probe in high-heat areas?
• A: Yes – the extended temp option (PFA cable) supports up to +260°C for connectors and +218°C for the probe tip.
• – Q: How does 1.0m length help?
• A: It’s shorter and lighter than longer probes, making it easier to install in tight spaces without compromising signal quality.
• – Q: Is pressure testing available?
• A: Probes aren’t pre-tested, but contact Bently Nevada’s custom design team for application-specific pressure checks.
