Description
Product Overview
The Bently Nevada 330101-00-96-20-02-CN is a premium 8mm eddy current vibration probe from the trusted 3300 XL series. Designed for industrial machinery monitoring, it offers superior durability with patented TipLoc and CableLoc technology. This robust probe ensures reliable radial vibration and position measurement in demanding environments. We recommend it for critical applications where equipment protection is essential.
Model Configuration
- Base Model: 330101 – 3300 XL 8 mm Probe
- Unthreaded Length (00): 0.0 inches
- Case Length (96): 9.6 inches
- Cable Length (20): 2.0 meters (6.6 feet)
- Connector (02): Miniature coaxial ClickLoc
- Variant (CN): Country Specific
Technical Specifications
- Brand & Series: Bently Nevada 3300 XL
- Type: 8mm Non-Armored Eddy Current Probe
- Core Performance
- Linear Range: 2.0 mm (80 mils)
- Recommended Gap: 1.27 mm (50 mils) = -9 Vdc
- Sensitivity (ISF): 7.87 V/mm (200 mV/mil)
- Linearity (DSL): Better than ±0.025 mm (±1 mil)
- Electrical Data
- Probe Resistance: 7.88 Ω ± 0.50 Ω
- Cable Capacitance: 69.9 pF/m typical
- Max Field Wiring: 305 meters (1000 feet)
- Environmental Ratings
- Temp Range (Standard): -52°C to +177°C
- Temp Range (Extended): Up to +218°C
- Pressure Seal: Viton® O-ring
- Humidity: <3% ASF change at 93% RH
- Mechanical Construction
- Thread: 3/8-24 UNF
- Case Material: AISI 303/304 Stainless Steel
- Tip Material: Molded PPS Plastic
- Cable Pull Strength: 330 N (75 lbf)
Installation & Setup
Mount the probe using the 3/8-24 UNF thread. Set the initial gap to achieve -9 Vdc output for optimal radial vibration measurement. Use the ClickLoc connector for secure, tool-free cable connection. For field wiring, we recommend using shielded triad cable (0.2-1.5 mm²). Ensure proper grounding to minimize electrical noise interference.
Compatibility
This probe is compatible with Bently Nevada 3300 XL Proximitor sensors and related monitoring systems. It connects seamlessly with matching miniature ClickLoc extension cables. The 8mm diameter fits standard mounting holes in most industrial machinery.
Quality Assurance
- Manufactured by Bently Nevada in the USA
- Designed to meet industrial standards
- Warranty: 12 months from purchase date
Shipping & Delivery
We ship worldwide via FedEx, UPS, and DHL. Typical delivery times are 3-7 business days for most regions. Contact us for expedited shipping options.
Application Scenarios
- Continuous vibration monitoring of turbines and compressors
- Shaft position measurement in pumps and motors
- Predictive maintenance in power generation plants
- Condition monitoring in oil & gas applications
Selection Guide
Choose this standard 8mm probe for most vibration monitoring needs. Select armored versions in high-abrasion areas. For wet environments, consider the FluidLoc option. Always verify thread compatibility with your equipment. Contact our technical team for application-specific recommendations.
