3300 XL 8mm Proximity Probe by Bently Nevada – Model 330101-00-12-90-02-00

Description

Product Identity Tree (Model Structure)

• Brand: Bently Nevada
• Series: 3300 XL
• Type: 8 mm Proximity Probe
• Full Model: 330101-00-12-90-02-00
• Suffix Breakdown
  • 330101 →3300 XL 8mm Probe

  • 00 → Unthreaded length: 0.0 in
  • 12 → Case length: 1.2 in
  • 90 → Total cable length: 9.0 m
  • 02 → Miniature ClickLoc coax connector
  • 00 → No extra option required

Main Technical Specifications

• Probe diameter: 8 mm rugged body
• Thread type: 3/8-24 UNF
• Nominal probe resistance: 9.87 Ω ±0.50
• Extension cable capacitance: ~69.9 pF/m
• Linear measurement range: up to 2.3 mm
• Recommended vibration gap: about 1.27 mm
• Scale factor output: 7.87 V/mm typical
• Max field wiring distance: 305 m supported

Material & Durability Features

• Probe tip material: PPS molded plastic
• Case material: Stainless steel 303/304
• Strong pull strength design: up to 330 N
• Better sealing with Viton O-ring structure
• Optional FluidLoc design helps block oil leaks

Environmental Performance

• Standard temp range: -52°C to +177°C
• Extended probe tip range: up to +218°C
• Humidity stability: less than 3% drift
• Protection suited for indoor industrial systems

Key Selling Points

• More rugged than older probe designs
• Stable output for turbine vibration monitoring
• Secure connector for fast installation
• Best choice for harsh machine environments
• Trusted U.S.A made quality standard

Warranty & Shipping Terms

• Warranty: 12 months full support
• Each unit is inspected before dispatch
• Worldwide shipping via FedEx, UPS, DHL
• Fast export packing for industrial delivery

FAQ – Selection & Practical Guide

• How do I confirm this probe fits my machine?
  Check thread size, cable length, and required gap range.
• Why choose an 8 mm probe instead of smaller types?
  8 mm units are stronger and handle physical stress better.
• Is a 9 meter cable good for long-distance installs?
  Yes. It reduces the need for extra extensions in many cases.
• What is the best gap setting in real use?
  Many engineers use around -9 Vdc for stable vibration readings.
• What should buyers check before ordering?
  Confirm suffix code, connector type, and temperature limits.
