Description
Overview
The Bently Nevada 3300 XL 8 mm Probe (Product No. 330140-08-30-11-05) is engineered for extended-reach applications in demanding industrial environments. Featuring a 3.0-meter FluidLoc cable and ClickLoc connector, it prevents fluid ingress while ensuring secure, long-distance installations.
Technical Specifications
- Brand: Bently Nevada
- Model: 3300 XL 8 mm Probe
- 330140-08-30-11-05 Suffix Breakdown:
- 08: 0.8-inch case length
- 30: 3.0-meter cable (9.8 feet)
- 11: Miniature coaxial ClickLoc connector with connector protector, FluidLoc cable
- 05: CSA, ATEX, IECEx Approvals
- DC Resistance: 8.15 Ω ±0.52 (3.0m cable)
- Scale Factor (ISF):
- Standard (1/5m): 7.88 V/mm ±4.3%
- Extended (9m): 7.88 V/mm ±6.0%
- Deviation from Straight Line (DSL):
- Standard (1/5m): < ±0.029 mm (±1.14 mil)
- Extended (9m): < ±0.042 mm (±1.65 mil)
- Materials: PPS tip, AISI 316 stainless steel case
- Weight: 336 g/m (11.9 oz/ft)
- Pull Strength: 355 N (79.8 lbf) via CableLoc
- Humidity Tolerance: < 2.3% ASF shift at 94% humidity (IEC 68-2-3, 60 days)
Contact Information
For certification documents and lead times:
Email: sales@ubestplc.com
Explore more detailed information in official datasheet here: 3300 XL 8 mm Proximity Transducer System Datasheet
