Description
Product Overview
The Bently Nevada 3300 XL 8 mm Probe (Model 330140-08-50-11-05) is a high-performance, certification-ready solution for demanding industrial environments. Engineered with a 5.0-meter FluidLoc cable and a ClickLoc connector protector, this probe prevents fluid ingress while ensuring secure connectivity in high-vibration settings.
Technical Specifications
- Brand: Bently Nevada
- Model: 330140-08-50-11-05
- Suffix Breakdown:
- 08: 0.8-inch case length
- 50: 5.0-meter cable (16.4 feet)
- 11: ClickLoc connector with protector + FluidLoc cable
- 05: CSA, ATEX, IECEx certifications
- Suffix Breakdown:
- Probe Tip: Polyphenylene sulfide (PPS)
- Case Material: AISI 303/304 stainless steel
- Temperature Range:
- Standard: -62°F to +350°F (-52°C to +177°C)
- Extended: Tip up to +425°F (+218°C); cable/connector up to +500°F (+260°C)
- DC Resistance: 8.73 Ω ±0.50 (5.0-meter length)
- Scale Factor: 7.87 V/mm ±5% (1/5m systems) or ±6.5% (9m/ETR systems)
- Linearity Deviation: <±0.025 mm (1 mil) for 1/5m; <±0.038 mm (1.5 mil) for 9m/ETR
- Humidity Resistance: <3% ASF change at 93% humidity (56 days, IEC 68-2-3)
- Fluid Resistance: IP69K-rated for high-pressure/high-temperature washdowns
- EMC Compliance: Exceeds EN 55011 Class A for industrial EMI suppression
- Shock Resistance: 100 g (6 ms, 3 axes) per IEC 60068-2-27
Contact Information
For inquiries or custom configurations, email sales@ubestplc.com. Our team will gladly assist with technical details or order processing.
Explore more detailed information in official datasheet here: 3300 XL 8 mm Proximity Transducer System Datasheet
