330195-02-12-90-CN Bently Nevada 3300 XL 8 mm ETR Reverse Mount Probe

Description

Bently Nevada 330195-02-12-90-CN – Long-Range Reverse Mount Probe

???? Suffix Decoded

330195-02-12-90-CN
├─ 330195: 8mm reverse mount base model
├─ 02: 3/8-24 UNF thread
├─ 12: 12mm unthreaded section
├─ 90: 9.0m (29.5ft) cable
└─ CN: Country-specific certifications

???? Key Specifications for 330195-02-12-90-CN

• Electrical:
  – Power: -17.5V to -26V DC | 12mA max
  – Resistance: 9.87Ω ±0.50 (center to outer conductor)
• Mechanical:
  – Material: PPS tip + AISI 304 SST case
  – Max thread engagement: 14.3mm (0.563″)
• Environmental:
  – Temp: -52°C to +177°C (Standard) | +218°C (tip)/+260°C (cable)
  – Humidity: <3% ASF drift @93% RH (56 days)

???? Industrial Applications

• ⚡ Offshore Platforms: Subsea compressor monitoring
• ????️ Paper Mills: Long-distance roller bearing analysis
• ????️ Pipeline Systems: Remote pump station diagnostics

⚠️ Critical Notes

• ❌ Minimum install temp: -34°C (-30°F)
• ???? Requires 3300/42M monitor compatibility
• ???? COO available upon request
