Description
Bently Nevada 330301-000-011-10-90-00-00: Heavy-Duty High Temp Vibration Probe
Get detailed specs & install tips: Download Manual Now
Why Choose This Probe?
- ???? Extra large design: 3/4-16 UNF threads for secure mounting
- ????️ Heat resistant: Works from -34°C to 350°C (-30°F to 662°F)
- ???? Safe ceramic tip: Won’t damage machinery surfaces
- ???? Ready to ship: Dispatched same day
Product Code Breakdown
MODEL 330301
▸ Base: XL High Temp Probe
▸ Threads: 3/4-16 UNF
CONFIGURATION
- • 000: 0″ unthreaded length
- • 011: 1.1″ case length
- • 10: 1.0m hard cable
- • 90: 9.0m total cable
- • 00: No armor
- • 00: No approvals
Key Measurements
- ⚖️ Weight: 117g/m cable + 12g/cm body
- ???? Accuracy: ±78μm deviation
- ???? Resistance: 5.06 Ω (1m cable)
- ???? Signal range: Works with 305m wiring
- ???? Target size: Min 30.5mm diameter
Technical Highlights
- ✅ Linear range: 4.0mm (160 mil)
- ✅ Sensitivity: 3.94 V/mm ±9.65%
- ✅ Response speed: 0-6,000 Hz detection
- ✅ Material: 316L stainless steel body
- ✅ Temp stable: ±30% sensitivity from 22-350°C
Package & Support
- High temperature vibration probe
- 9.0 meter cable
- Calibration papers
- 12-month warranty
- Fast shipping: FedEx, UPS, DHL
Common Questions
- Q: Thread size for installation?
A: 3/4-16 UNF threads - Q: Cable protection level?
A: Standard jacket (no armor) - Q: Minimum shaft size?
A: 152mm (6.0 inch) diameter - Q: Power requirements?
A: Works with standard monitoring systems - Q: International shipping?
A: Yes – ships worldwide
Need wiring diagrams? Download Full Technical Guide
