Description

Bently Nevada 330505-03-02-02 Low Frequency Velocity Sensor

New & original factory-sealed vibration sensor for industrial machinery monitoring. Hermetically sealed stainless steel casing. Includes 12-month warranty.

Technical Specifications

• Brand: Bently Nevada
• Model: 330505-03-02-02 (Full Suffix Breakdown:
  -03: 180° Mounting,
  -02: 3/8-24 UNF Thread,
  -02: M8 Adapter)
• Range: 102 mm/s (4 in/s) peak
• Accuracy: ±0.9 dB (1-200 Hz)
• Output: 20 mV/mm/s ±10%, -12V DC bias
• Temp Range: -40°C to +100°C
• Frequency Response: 0.5-1000 Hz
• Cable Length: 305m (with 3500/46M)
• Shock Survival: 100g peak

Installation Guide

• Mounting Angle: 180° ±10°
• Torque Limit: 46 kg cm (40 in-lb)
• Polarity: Pin A+ when base-to-top motion detected
• Sealed connector: 2-pin Mil-C-5015

Compatibility

Works with Bently Nevada 3500/46M systems. Compatible with turbines, motors, and gearboxes using M8/3/8-24 UNF mounts.

Certification & Build

• IP68 equivalent (hermetic seal)
• Stainless steel 300 series casing
• Weight: 375g (13.2oz)

Package & Warranty

• Factory-sealed sensor with documentation
• 12-month warranty
• Shipping: FedEx, UPS, DHL (global 2-5 days)

FAQ

Q: Humidity tolerance?
A: 100% non-submerged operation

Q: Cable length limit?
A: 305m with 3500/46M system

Q: Thread size options?
A: 3/8-24 UNF or M8 adapter included
