Bently Nevada 3300 XL 11mm Proximity Probe – Industrial Precision for Critical Machinery
Monitor equipment health with Bently Nevada‘s high-performance 11mm proximity probe. Engineered in the USA with aerospace-grade materials, this sensor delivers reliable vibration data in extreme conditions (-51°C to +177°C). Features PPS probe tip and stainless steel case for durability.
KEY FEATURES
- Premium Materials: PPS tip + AISI 304 SST case
- Extreme Temperature: -51°C to +177°C operation
- Sealed Design: Viton O-ring pressure seal
- Easy Installation: 1/2-20 UNF threaded case
- FluidLoc cable with ClickLoc connector
TECHNICAL SPECIFICATIONS
- Brand: Bently Nevada
- Full Model: 330701-00-24-10-12-00
- Probe Type: 11mm Triaxial Proximity Sensor
- Cable Length: 1.0 meter (3.3 ft)
- Resistance: 5.9Ω ±0.5Ω (center to outer conductor)
- Cable Type: 75Ω Triaxial FEP-insulated
- Thread Size: 1/2-20 UNF
- Max Torque: 15.2 N•m (recommended)
- Bend Radius: 25.4mm (1.0 in)
- Weight: 0.17kg (0.37 lbs)
INSTALLATION GUIDE
- Apply max 15.2 N•m torque to case
- Limit thread engagement to 0.75 in (19mm)
- Hand-tighten connectors (max 0.565 N•m)
- Avoid temperatures below -34°C before installation
COMPATIBILITY
- Works with all 3300 XL monitoring systems
- Miniature ClickLoc connector interface
- Standard 1/2-20 UNF mounting holes
CERTIFICATIONS & PACKAGE
- Certificate of Origin (COO) available
- Made in USA compliance
- 12-month warranty against defects
- Shipping via FedEx/UPS/DHL
FAQ
- Q: Pressure rating?
A: Contact custom department for pressure testing - Q: Alternative cable lengths?
A: Available in 1m/5m/9m options - Q: Minimum install temperature?
A: Do not install below -34°C (-29°F)
