Description
Bently Nevada 3300 XL 11mm Proximity Probe: Precision Vibration Monitoring
Industrial-grade vibration sensor with armored triaxial cable and chemical-resistant PPS tip. Designed for critical machinery health diagnostics in harsh environments. Ships worldwide with 12-month warranty.
Technical Specifications
- Brand: Bently Nevada
- Model: 3300 XL 11mm Proximity Probe
- Full Part Number: 330702-00-10-50-02-00
- Configuration Breakdown:
- 00: 0″ unthreaded length
- 10: 1.0″ case length
- 50: 5.0 meter cable (16.4 ft)
- 02: ClickLoc mini-coaxial connector
- 00: No agency approval required
- Electrical: 7.2 Ω ±0.8 DC resistance
- Cable: 75 Ω triaxial, FEP-insulated, armored
- Temperature Range: -51°C to +177°C
- Thread: 1/2-20 UNF
- Case Torque: 15.2 N·m recommended (45.2 N·m max)
- Min. Bend Radius: 25.4 mm (1.0 in)
Installation & Compatibility
- ⚠️ Must use with 5-meter Proximitor sensors ONLY
- Tip Material: PPS (chemical/heat resistant)
- Case Material: AISI 304 Stainless Steel
- Pressure Seal: Viton O-ring (contact for custom testing)
Certification & Support
- Certificate of Origin: Available on request
- Warranty: 12 months
- Shipping: FedEx, UPS, DHL (0.17 kg)
Frequently Asked Questions
- Q: Compatible with 1m/9m Proximitors?
A: No – designed exclusively for 5m systems - Q: Pressure rating for seals?
A: Contact for custom pressure testing - Q: Waterproof rating?
A: FEP insulation provides chemical resistance
