Description
Bently Nevada 330707-00-10-90-12-05 Proximity Probe
Premium 9.0m FluidLoc sensor with multiple certifications for harsh industrial environments. Made in USA with global shipping.
Product Identification
Brand: Bently Nevada
Model: 3300 XL 11mm Probe
Full Code: 330707-00-10-90-12-05
Part Number Breakdown:
- 330707: 5/8-18 UNF no armor
- 00: 0 inch unthreaded
- 10: 1.0 inch case
- 90: 9.0 meter cable
- 12: FluidLoc cable
- 05: Multiple approvals
Technical Specifications
- Resistance: 8.5Ω ±1.1Ω
- Temp range: -51°C to +177°C
- Weight: 0.17 kg
- Min bend: 25.4mm radius
- Thread torque: 15.2 N•m max
- Seal material: Viton O-ring
- Cold limit: >-34°C for seals
- Cable type: Triaxial FEP
- Thread size: 5/8-18 UNF
- Engagement: 0.938 inch max
Installation Guide
- Finger-tight connector torque
- Maintain 25.4mm bend radius
- Max 0.938 inch thread engagement
- Keep above -34°C for seal life
Package & Support
- New probe in factory packaging
- 12-month warranty coverage
- Global shipping services
Technical Questions
Q: FluidLoc vs standard cable?
A: Better chemical/oil resistance
Q: Max thread torque value?
A: 45.2 N•m (400 in•lb)
Q: Cable insulation material?
A: FEP (fluoroethylene propylene)
Q: UNF thread meaning?
A: Unified National Fine standard
Q: Warranty claims process?
A: Contact with proof of purchase
