Description:
The Allen-Bradley 1794-IE8XOE4 Output Analog Module is engineered to provide precise and reliable analog output control for a wide range of industrial applications. This module features 8 single-ended, non-isolated input channels that support both current and voltage inputs. Additionally, it offers 4 output channels with a voltage range of 0 to 10V DC, making it suitable for controlling various equipment or processes. The module’s robust environmental specifications ensure its operation in diverse conditions, making it ideal for applications in harsh industrial environments.
Technical Data:
| Attribute | Value |
|---|---|
| Brand | Allen-Bradley |
| Model | 1794-IE8XOE4 |
| Input Specifications | 8 single-ended, non-isolated |
| Input Range (Current) | 0 to 20 mA |
| Input Range (Voltage) | 0 to 10 Volts DC |
| Resolution (Voltage) | 320 µV/count |
| Resolution (Current) | 0.641 µA/count |
| Conversion Type | Successive approximation |
| Conversion Rate | 8.0 ms for all channels |
| Input Current Terminal | Configurable for 4.0 mA or 0.0 mA |
| Output Specifications | 4 outputs |
| Output Range (Voltage) | 0 to 10 Volts DC |
| Output Current Rating | Configurable to support various load requirements |
| Nominal Voltage | 24 Volts DC |
| Power Consumption | Approximately 200 mA @ 24V DC |
| Operating Temperature | 0 to 60 °C (32 to 140 °F) |
| Storage Temperature | -40 to 85 °C (-40 to 185 °F) |
| Relative Humidity | 5% to 95% non-condensing |
